Agricultural tank
MB50 – MB35EX – MB38 M.R.
MB50 (Approval: Italian 5 TON)
Capacity: Lt. 3.850
Tare without wheels: 1700 Kg
Maximum length without wheels: 4850 mm
Maximum width without wheels: 2170 mm
Maximum height without wheels: 2100 mm
Diameter tank: 1300 mm
Axles: n. 1 Q.70
Brake type: Mechanic ÷ Hydraulic ÷ Pneumatic
Suction pump: MEC5000 ÷ 6500 ÷ 8000
Type of approval: Italian 5 TON
Wheels: 385/65R22.5 ÷ 425/65R22.5 ÷ 550/45-22.5
MB35EX (Approval: Foreign 5 TON without approval only CE certification)
Capacity: Lt. 3.850
Tare without wheels: 1700 Kg
Maximum length without wheels: 4850 mm
Maximum width without wheels: 2170 mm
Maximum height without wheels: 2100 mm
Diameter tank: 1300 mm
Axles: n. 1 Q.70
Brake type: Hydraulic ÷ Pneumatic
Suction pump: MEC5000 ÷ 6500 ÷ 8000
Type of approval: Foreign 5 TON without approval only CE certification
Wheels: 385/65R22.5 ÷ 550/45-22.5
MB38 M.R. (Approval: European 5,3 TON)
Capacity: Lt. 3.850
Tare without wheels: 1700 Kg
Maximum length without wheels: 4850 mm
Maximum width without wheels: 2170 mm
Maximum height without wheels: 2100 mm
Diameter tank: 1300 mm
Axles: n. 1 Q.70
Brake type: Pneumatic
Suction pump: MEC5000 ÷ 6500 ÷ 8000
Type of approval: European 5,3 TON
Wheels: 385/65R22.5 ÷ 425/65R22.5 ÷ 400/60-15.5 19.045-17 ÷ 500/50-17÷550/45-22.5÷560/45R22.5
Accessories
AVAILABLE colors
RED RAL 3000
YELLOW VAIA
GREEN JOHN DEERE
GREEN FENDT
GREEN DEUTZ
GREEN CLASS
LIGHT BLUE LANDINI
BLUE NEW HOLLAND
BLACK OPACO ISO 90
BLACK LUCIDO
